| SPECIFICATIONS |
|---|
| Measuring function |
: |
AC load current |
|---|
| Safety standard |
: |
IEC61010-1, IEC61010-2-032
Installation Category.
CategoryⅢ600V |
|---|
| Max Jaw Opening capability |
: |
108mm (108x128mm) |
|---|
| Measuring range |
: |
AC30A/300A/3000A (50/60Hz)
3 ranges manual |
|---|
| Accuracy |
: |
23℃±5℃ 80%RH or less (50/60Hz)
| Range |
Resolution |
Accuracy(50/60Hz) |
|---|
|
AC 30A |
0.01A |
±1.5%rdg±8dgt | |
AC 300A |
0.1A | |
AC 3000A |
1A |
±2.0%rdg±8dgt |
|
|---|
| Measuring method |
: |
Dual slope integration mode |
|---|
| AC conversion |
: |
AC coupled true rms responding |
|---|
| Display |
: |
LCD, max. 3200 count with annunciators |
|---|
| Over range indication |
: |
"OL" mark on LCD |
|---|
| Low battery indication |
: |
"Battery" mark on LCD |
|---|
| Data hold indication |
: |
"DH" mark on LCD |
|---|
| Sampling |
: |
2 times/sec |
|---|
| Auto power off function |
: |
The meter is set to power off Approx. 10 minute later after power on. |
|---|
| Limitation of circuit voltage |
: |
Less than AC 600V |
|---|
| Withstanding voltage |
: |
AC 5500V, 1 minute (between operation handle and core of CT) |
|---|
| Operating temperature |
: |
0℃ - 40℃, less than 80%RH (Without condensation) |
|---|
| Storage temperature |
: |
-10℃ - 60℃, less than 70%RH (Without condensation) |
|---|
| Power supply |
: |
1.5V battery[UM-4 or AAA size]x 2 |
|---|
| Power consumption |
: |
Approx. 6mW |
|---|
| Battery life |
: |
Approx. 200 hours continuous |
|---|
| Dimension and weight |
: |
194(W) x 341.5(H) x 52(D) mm, Approx. 1.8kgs |
|---|
| Accessories |
: |
| Battery (UM-4) |
: 2 | | Instruction Manual |
: 1 | | Carrying Case |
: 1 | | Hand Strap |
: 1 |
|
|---|
